Black Eaton 9SX UPS 700VA 630W Kartu Jaringan Opsional Menara UPS 9SX700I
Eaton 9SX UPS 700VA 630W Kartu Jaringan Opsional Menara UPS 9SX700I Eaton 9SX (700VA-3kVA) UPS Eaton 9SX UPS menawarkan ketersediaan tinggi, fleksibilitas dan perlindungan canggih untuk infrastruktur, industri, medis, TI, jaringan, penyimpanan dan telekomunikasi.Memberikan perlindungan konversi ...
Black Eaton 9SX UPS
,Eaton 9SX UPS 700VA
,9SX700I
Eaton 9SX UPS 700VA 630W Kartu Jaringan Opsional Menara UPS 9SX700I
Eaton 9SX (700VA-3kVA) UPS
Eaton 9SX UPS menawarkan ketersediaan tinggi, fleksibilitas dan perlindungan canggih untuk infrastruktur, industri, medis, TI, jaringan, penyimpanan dan telekomunikasi.Memberikan perlindungan konversi ganda online dalam format menara yang nyaman
Spesifikasi
| Topologi UPS | Konversi ganda (Online) |
| Kapasitas daya output | 0.7 kVA |
| Kekuatan output | 630 W |
| Bentuk gelombang | Sinus murni |
| Tegangan operasi input (min) | 120 V |
| Tegangan operasi input (max) | 276 V |
| Frekuensi input | 40/70 Hz |
| Tegangan operasi output (min) | 200 V |
| Tegangan operasi output (max) | 240 V |
| Frekuensi output | 50/60 Hz |
| Jumlah fase input | 1 |
| Jumlah fase output | 1 |
| Faktor daya | 0.9 |
| Mode ECO | N |
| Tingkat kebisingan | 40 dB |
| Jenis outlet AC | C13 kopling |
| Plug listrik | C14 kopling |
| Jumlah outlet AC | 6 outlet AC (s) |
| Port USB | Y |
| Jumlah port USB 2.0 | 1 |
| Antarmuka serial | Y |
| Port RS-232 | 1 |
| Teknologi baterai | Asam Timah yang Disegel (VRLA) |
| Waktu cadangan khas pada setengah beban | 14 menit |
| Baterai hot-swap | Y |
| Tes baterai otomatis | Y |
| Faktor bentuk | Menara Mini |
| Warna produk | Hitam |
| Tampilan | LCD |
| Keamanan | IEC/EN 62040-1, UL 1778, CSA 22.2 |
| Sertifikasi | IEC/EN 62040-1, UL 1778, CSA 22.2, IEC/EN 62040-2, FCC Kelas B, CISPR22 Kelas B, laporan CE / CB (TUV) / cULus / EAC / RCM / BIS / KCC |
| Suhu operasi (T-T) | 0 - 40 °C |
| Lebar | 160 mm |
| Kedalaman | 357 mm |
| Ketinggian | 252 mm |
| Berat badan | 110,5 kg |
| Kartu manajemen termasuk | N |
| Perangkat lunak yang dikemas | Smart Power Software suite |
| Jenis koneksi input | IEC C14 |
| Tegangan output nominal | 230 V |
| Tegangan masuk nominal | 230 V |
-
